Models Available
| DOUW-4838-MR | 48 ¼”L x 54 ½"D x 52 ⅛"H | Remote Front Self-Service Display, Rear Preparation Station |
| DOUW-6038-MR | 60 ⅜”L x 54 ½"D x 52 ⅛"H | Remote Front Self-Service Display, Rear Preparation Station |
| DOUW-7238-MR | 72 ½”L x 54 ½"D x 52 ⅛"H | Remote Front Self-Service Display, Rear Preparation Station |
| DOUW-9638-MR | 96 ½”L x 54 ½"D x 52 ⅛"H | Remote Front Self-Service Display, Rear Preparation Station |
Features
- Brushed stainless steel internal cabinet construction.
- Many exterior finish options available: powder coat paint, brushed stainless steel, decorative laminates and natural wood finishes.
- Three interior finish options: textured powder coat black, white and brushed stainless steel.
- The front décor panel can be extended to provide a more finished cabinet look.
- Other custom options are offered. Refer to the options schedule on the next page.
- The refrigerated front self-service display has a LED light strip mounted to the top ledge of the display area, and one 12”D adjustable metal shelf with a front product stop and LED light strip mounted to the bottom of the shelf.
- The refrigerated rear storage cabinet is constructed of brushed stainless steel and has rear thermal sliding doors.
- The top preparation area has an integrated front refrigerated well to hold a series of food pans. The prep counter is brushed stainless steel and has a removeable 12” white nylon cutting board.
- The top preparation area is protected with a front mounted tempered glass sneeze guard, top shelf and end panels.
- Designed to maintain the critical temperature of the products within the display, the storage cabinet and the top refrigerated well at a range of 38-41°F (3-5°C) with an ambient atmosphere of 75°F (24°C)/55% humidity.
- ETL electrical certification and NSF-7 standards.
- The refrigeration system is located below the rear storage cabinet, pulling fresh air from the far right side of the display and exhausting heat on the far left.
- The refrigeration system is adjusted by two temperature controllers, one to control the front and top display and the other to control the rear storage cabinet.
Additional Features
- Designed to maintain the critical temperature of the products within the display at a range of 38-41°F (3-5°C) with an ambient atmosphere of 75°F (24°C)/55% humidity. Designed for holding pre chilled product only
- Electrical condensate evaporation system
- ETL listed and sanitation certified to NSF 7
- 1 year parts and labor warranty
Custom Options & Technical Specs
- Please refer to spec sheets
- Contact Cayuga Sales Rep for custom options
- For technical specifications please refer to spec sheets
